Hopper Dryers

Sep 04, 2017

The moisture in the Plastic Resins (Hygroscopic and Non-Hygroscopic) will effect the surface finish and quality of the molded component. We have designed a compact and economical HOT AIR HOPPER DRYER to overcome this problem.   Features Drying capacities ranges from 25 Kgs to 100 kgs Direct Machine mounting Tubular type heaters for longer heater life Solid state temperature controller for reliability Process air temperatures to 150°C and higher with options Fiber glass insulation optional Low power consumption Specially designed diffuser cone for uniform heating and drying Detachable air distribution system for easy cleaning   Technical Specifications   Model Hopper Capacity Kgs. Heater Load KW Blower Load KW Dimensions Dia mm Heigth mm HAHD-25 25 3 0.16 475 750 HAHD-50 50 4.5 0.16 475 1000 HAHD-75 75 6 0.18 550 1250 HAHD-100 100 9 0.37 550 150   Hopper Dryer Attachments We offer an unique system to convert existing hopper into dryer just be replacing the top lid of the existing hopper.   Features Heat insulated air duct Thermostatic control of temperature Economical and low power consumption Easy to fix over the existing hopper Modular type heating element for effective and efficient heat transfer   Dimensions   Model Duct Depth(mm) Duct Dia(mm) Base Dia(mm) Heater load (Watts) Volts PF-50 300 50 50 750 230 PF-60 300-400 60 120 1000 230 PF-70 450-600 70 140 1250 230 PF-90 600-900 90 180 1500 230
